Heavy-Duty Excavator Mounted Auger Attachments
Transform your excavator into a high-speed, vertical drilling rig. Our excavator-mounted hydraulic earth augers are engineered to handle the toughest drilling conditions. From soft topsoil to hard, fractured rock strata, these attachments deliver optimal torque transfer, maximum durability, and low operational costs. They are perfect for solar panel installations, utility pole erection, fencing, tree planting, and foundation micro-piling.
Technical Specifications & Series Matrix
Our auger drives are engineered with heavy-duty planetary gearboxes and premium hydraulic motors to match various carrier weights flawlessly.
| Specification Parameter | Compact Series (3T - 8T) | Medium Series (10T - 20T) | Heavy Duty Series (20T - 30T) |
|---|---|---|---|
| Carrier Compatibility | 3 - 8 Ton Excavators | 10 - 20 Ton Excavators | 20 - 30 Ton Excavators |
| Output Torque Range | 1,500 Nm – 4,500 Nm | 6,000 Nm – 15,000 Nm | 18,000 Nm – 35,000 Nm |
| Max Hydraulic Pressure | 205 Bar (3,000 PSI) | 240 Bar (3,500 PSI) | 260 Bar (3,770 PSI) |
| Oil Flow Requirement | 40 – 90 LPM | 80 – 170 LPM | 120 – 240 LPM |
| Standard Flight Diameters | 150 mm to 450 mm | 300 mm to 750 mm | 450 mm to 1200 mm |
| Standard Drilling Depth | 1.5 Metres | 2.0 Metres | 2.5 Metres |
| Extension Options | 1.0m Telescopic Extension | 1.5m / 2.0m Solid Extension | 2.0m / 3.0m Heavy Duty Solid |
| Hub/Shaft Connection | 65mm Round / 75mm Square | 75mm Square | 100mm Square |
Advanced Engineering Features
- Premium Sealed Planetary Gearbox: Multiplies hydraulic power into extreme rotational torque while fully protecting internal gears from dust, dirt, and moisture.
- Bi-Directional Hydraulic Drive: Features built-in reverse rotation to clear soil effortlessly from the flight and easily back out if it encounters underground blockages.
